Siv Rough Terrain Scissor Lift
Peb Siv Rough Terrain Scissor Lift npog SPR1023RT / SPR1323RT / SPR1623RT, ua haujlwm qhov siab ntawm 12.0m txog 18.2m. Tsim los ntawm Deutz D2.9L diesel cav nrog 110L roj tank, 4WD+2WS tag nrho- log tsav ntxiv rau ua npuas ncauj- cov log tsheb tau ntim cov av nkos, tsis sib xws sab nraum zoov kev tsim kho av.
Lub platform tseem ceeb tuaj nrog dual - sab txuas ntxiv, lub hauv paus rated load 680-1150kg ntxiv rau ntxiv 230kg ntxiv load nqa mus txog 7 tus neeg ua haujlwm thiab cov khoom tsim kho. Ib qho -nias outrigger leveling txhawb nqa ± 7℃longitudinal & ± 12℃lateral struts kho kom haum rau kev ua haujlwm ruaj khov ntawm txoj kab nqes, max gradeability nce mus txog 40% ~ 50%.
Tag nrho cov cav tov dhau tag nrho cov kev soj ntsuam thiab overhaul ntawm hydraulic thiab kev nyab xeeb qhov chaw, nruab nrog qaij xauv thiab overload tiv thaiv. Zoo tagnrho rau kev tsim kho vaj tse sab nraum zoov, chaw nres nkoj overhaul thiab loj - thaj chaw tu nrog cov nqi ua tau zoo.
Specifications
|
Hom khoom |
SPR-1023RT |
SPR-1323RT |
SPR-1623 RT NWS |
|
Loj |
|||
|
Qhov siab ua haujlwm siab tshaj plaws |
12.0m |
15.1m |
18.2m |
|
Qhov siab tshaj plaws platform |
10.0m |
13.1m |
16.2m |
|
Zuag qhia tag nrho ntev |
4.88 m |
4.88 m |
4.88 m |
|
Dav dav |
2.30 m |
2.30m |
2.30 m |
|
Zuag qhia tag nrho qhov siab (unfolded laj kab) |
2.75 m |
2.95 m |
3.15m |
|
Zuag qhia tag nrho qhov siab (folded laj kab) |
2.1m |
2.3m |
2.5m |
|
Ua haujlwm platform qhov ntev (ntev x dav) |
3.98x1.83 |
3.98x1.83 |
3.98x1.83 |
|
Platform extension loj |
Pem hauv ntej 1.5m / rear 1.2m |
Pem hauv ntej 1.5m / rear 1.2m |
Pem hauv ntej 1.5m / rear 1.2m |
|
Wheelbase |
2.85 m |
2.85m |
2.85 m |
|
Hauv av dearance |
360 hli |
360 hli |
360 hli |
|
Kev ua tau zoo |
|||
|
Cov neeg ua haujlwm siab tshaj plaws |
7 |
7 |
7 |
|
RATED LOAD |
1 150kg |
6 80kg |
6 80kg |
|
Extended platform rated load |
2 30kg |
2 30kg |
2 30kg |
|
Tshuab mus ceev (Retracted state) |
6.1 km / h |
6.1 km / h |
6.1 km / h |
|
Tshuab mus ceev (Lifting xeev) |
1.1 km / h |
1.1 km / h |
1.1 km / h |
|
Lub sijhawm nce / poob |
50/35s |
55/45s |
60/50s |
|
Qib kawm |
50% |
50% |
40% |
|
Yam tsawg kawg nkaus tig vojvoog (lub log sab hauv) |
2.16m |
2.16m |
2.16m |
|
Yam tsawg kawg nkaus tig lub vojvoog (lub log sab nraud) |
5.33 m |
5.33 m |
5.33 m |
|
Lub kaum sab xis ua haujlwm siab tshaj plaws (pem hauv ntej-rau-rov qab) |
3 degree |
3 degree |
3 degree |
|
Qhov siab tshaj plaws tso cai ua haujlwm lub kaum sab xis (sab sab, ob txhais ceg retracted) |
2 degree |
2 degree |
2 degree |
|
Lub kaum sab xis ua haujlwm siab tshaj plaws (pem hauv ntej-rov qab, ob txhais ceg txuas ntxiv) |
0.8 degree |
0.8 degree |
0.8 degree |
|
Qhov siab tshaj plaws theem ntawm cov ceg txhawb nqa (pem hauv ntej- mus rau -rov qab) |
7 degree |
7 degree |
7 degree |
|
Qhov siab tshaj plaws ua haujlwm lub kaum sab xis (lateral) |
12 degree |
12 degree |
12 degree |
|
Tsav |
4 ws,2 ws |
4 ws,2 ws |
4 ws,2 ws |
|
Lub log |
33x12-20/Sold foam-filled |
33x12-20/Sold foam-filled |
33x12-20/Sold foam-filled |
|
Hwj chim |
|||
|
Lub zog |
Deutz D2.9L 5.36KW TSI |
Deutz D2.9L 5.36KW TSI |
Deutz D2.9L 5.36KW TSI |
|
Tswj voltage |
12V DC lub zog |
12V DC lub zog |
12V DC lub zog |
|
Roj tank peev xwm |
110L |
110L |
110L |
|
Hydraulic system muaj peev xwm |
110L |
110L |
110L |
|
Qhov hnyav |
|||
|
Tag nrho lub tshuab hnyav |
6 950kg |
7 230kg |
8 020kg |
